Rám
Foxy 29 6061 Alloy Stealth Evo, hydroformed tubing, Zero Suspension System, 150mm travel, Forward Geometry, one piece Monoblock upper link, Boost 12x148mm rear axle, 73mm BSA bottom bracket, dedicated 1x drivetrain design, telescopic seatpost internal routing, MAX capacity sealed bearings, ISCG 05
-
Vidlica
Fox 36 29 Float GRIP EVOL Rhythm, 160mm, tapered steerer tube, Boost 15x110mm axle, offset 44mm. Settings: sweep adjust compression, low-speed rebound, air preload
-
Radenie
Sram Trigger SX Eagle, 12s, X-Actuation 1:1
-
Kľuky
Sram SX Eagle, Boost, DUB axle, Direct Mount chain ring, S/M size: 170mm, L/XL size: 175mm
-
Riadidlá
Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9º backsweep, 5º upsweep, 31.8mm barbore
-
Sedlovka
Onoff Pija dropper internal, diameter 31.6mm, S size: 405x95-125mm, M size 458x120-150mm, L size: 498x140-170mm, XL size: 498x140-170mm
-
Náboj zadný
e*thirteen Boost 12x148mm, triple-sealed, fully machined aluminum w/6-degree engagement, IS 6 bolts, Shimano freehub
-
Kazeta
Sram PG-1210, 11-50T, 12s
-
Ráfiky
e*thirteen LG1 Enduro, IW30 Hookless, 6069 Welded Aluminum, 30mm internal width, tubeless ready, 28 spokes
-
Tlmič
Fox Float DPS LV EVOL Performance, 205x62.5mm. Settings: rebound, 3-position compression adjustment (Open/Mid/Lock), air preload. Trunnion top mount, 22.2x10mm bottom bushings
-
Nastavenia tlmiča
Light compression, light rebound, air volume spacer 0.6
-
Pätka k prehadzovačke
Mondraker M068
-
Rám
Foxy 29 6061 Alloy Stealth Evo, hydroformed tubing, Zero Suspension System, 150mm travel, Forward Geometry, one piece Monoblock upper link, Boost 12x148mm rear axle, 73mm BSA bottom bracket, dedicated 1x drivetrain design, telescopic seatpost internal routing, MAX capacity sealed bearings, ISCG 05
-
Hlavové zloženie
Onoff Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41x30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º
-
Prehadzovačka
Sram SX Eagle, Type 3 roller bearing clutch, cage lock, long cage, 1x12s, X-actuation 1:1
-
Brzdové páčky
Sram G2 R, tool-free reach adjust
-
Stredové zloženie
Sram DUB BSA, sealed bearings, 73mm
-
Predstavec
Onoff Sulfur FG 30mm 0º, 6061 forged alloy, 31.8mm barbore
-
Sedlo
SDG BEL-AIR 3.0, LPU foam, steel rails
-
Náboj predný
e*thirteen Boost 15x110mm, triple-sealed, fully machined aluminum, IS 6 bolts
-
Reťaz
Sram SX Eagle, 12s, Powerlock
-
Drôty
e*thirteen custom Hive triple-butted black steel, alloy nipples, nipple washers
-
Plášte
Maxxis Minion DHF 29x2.5 WT, tubeless ready, 3C MAXX TERRA compound, EXO+ protection, 120TPI, folding bead / Maxxis Minion DHF 29x2.5 WT, tubeless ready, 3C MAXX TERRA compound, EXO+ protection, 120TPI, folding bead
-
Gripy
Onoff Twin, 1lock-on, 135mm
-
Predná brzda
Sram G2 R, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads
-
Zadná brzda
Sram G2 R, 4-piston caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pads
-
Prevodník
32T, steel, X-Sync 2
