Rám

Chaser 6061 Alloy Stealth Evo, e-Bike Optimized Zero Suspension System, 150mm travel, Forward Geometry, internal removable battery, Boost 12x148mm rear axle, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 17mm axles, integrated dropout speed sensor, exclusive plastic motor covers, shock mudguard

Vidlica

Fox 36 29 Float FIT GRIP EVOL Rythm, 160mm, e-bike tuned, tapered steerer tube, Boost 15x110mm axle, 44mm offset. Settings: sweep adjust compression, Low-speed rebound, air preload

Prehadzovačka

Sram SX Eagle, Type 3 roller bearing clutch, cage lock, long cage, 1x12s, X-actuation 1:1

Hlavové zloženie

Onoff Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41x30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º

Brzdové páčky

Sram G2 R, tool-free reach adjust

Kľuky

Race Face Aeffect ebike, 165mm

Predstavec

Onoff Sulfur FG 30mm 0º, 6061 forged alloy, 31.8mm barbore

Riadidlá

Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9º backsweep, 5º upsweep, 31.8mm barbore

Sedlo

FIZIK Terra Aidon X5 145mm

Sedlovka

Onoff Pija dropper internal, diameter 31.6mm, S size: 387x125mm, M size: 425x150mm, L/XL size: 465x170mm

Náboj predný

Formula DC711, Boost 15x110mm, sealed bearings, IS 6 bolts

Náboj zadný

Formula EHL148 Boost 12x148mm, sealed bearings, IS 6 bolts

Kazeta

Sram PG-1210, 11-50T, 12s

Reťaz

Sram SX Eagle, 12s, Powerlock

Drôty

CN round stainless steel

Ráfiky

MDK-HP1 29, 30mm internal width, tubeless ready, 32 spokes

Predná brzda

Sram G2 R, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads

Zadná brzda

Sram G2 R, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads

Gripy

Onoff Diamond, 1lock-on, 135mm

Plášť

Maxxis Rekon 29x2.6, tubeless ready, dual compound, EXO protection, 60TPI, folding bead, Maxxis Rekon 29x2.6, tubeless ready, dual compound, EXO protection, 60TPI, folding bead

Prevodník

Sram X-Sync 2 Eagle 34T, steel, narrow-wide, 104 BCD

Pätka k prehadzovačke

Mondraker M068

Motor + Batéria

Bosch Performance Line CX Cruise (25Km/h) GEN4 BS3, Bosch Performance Line CX Cruise (25Km/h) GEN4 BS3 , Bosch Powertube 750Wh,Bosch Kiox 300

Hmotnosť

24,8 Kg
