Vidlica
RockShox 35 Gold 29 RL, 150mm, Solo Air, tapered steerer tube, Boost 15x110mm axle, 35mm steel stanchions, 44mm offset. Settings: compression adjustment at low-speed to lock, rebound, air preload
-
Radenie
Sram Trigger SX Eagle, 12s, X-Actuation 1:1
-
Kľuky
Sram SX Eagle, Boost, DUB axle, Direct Mount chain ring, S/M size: 170mm, L/XL size: 175mm
-
Riadidlá
Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9º backsweep, 5º upsweep, 31.8mm barbore
-
Sedlovka
Onoff Pija dropper internal, diameter 31.6mm, S size: 405x95-125mm, M size 458x120-150mm, L size: 498x140-170mm, XL size: 498x140-170mm
-
Náboj zadný
Formula DHT148 Boost 12x148mm, sealed bearings, IS 6 bolts
-
Kazeta
Sram PG-1210, 11-50T, 12s
-
Ráfiky
MDK-EP1 29, 30mm internal width, tubeless ready, 32 spokes
-
Tlmič
Fox Float DPS LV EVOL Performance, 205x57.5mm. Settings: rebound, 3-position compression adjustment (Open/Mid/Lock), air preload. Trunnion top mount, 30x8mm bottom bushings
-
Nastavenia tlmiča
Light compression, light rebound, air volume spacer 0.6
-
Pätka k prehadzovačke
Sram UDH
-
Rám
Raze 29 6061 Alloy Stealth Evo, hydroformed tubing, Zero Suspension System, 130mm travel, Forward Geometry, one piece Monoblock upper link, Boost 12x148mm rear axle, tapered head tube, 73mm BSA bottom bracket, dedicated 1x drivetrain design, telescopic seatpost internal routing, MAX capacity sealed bearings, ISCG 05
-
Hlavové zloženie
Onoff Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41x30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º
-
Prehadzovačka
Sram SX Eagle, Type 3 roller bearing clutch, cage lock, long cage, 1x12s, X-actuation 1:1
-
Brzdové páčky
Sram Level T, Direct Link actuation, tooled reach adjust, lever pivot bushings
-
Stredové zloženie
Sram DUB BSA, sealed bearings, 73mm
-
Predstavec
Onoff Sulfur FG 30mm 0º, 6061 forged alloy, 31.8mm barbore
-
Sedlo
MDK series PU 2023
-
Náboj predný
Formula DC711, Boost 15x110mm, sealed bearings, IS 6 bolts
-
Reťaz
Sram SX Eagle, 12s, Powerlock
-
Drôty
CN round stainless steel
-
Plášte
Maxxis Dissector 29x2.4 WT, tubeless ready, 3C MAXX TERRA compound, EXO+ protection, 120TPI, folding bead / Maxxis Aggressor 29x2.3, tubeless ready, dual compound, Exo protection, 60TPI, folding bead
-
Gripy
Onoff Twin, 1lock-on, 135mm
-
Predná brzda
Sram Level T, 2 piece caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pad
-
Zadná brzda
Sram Level T, 2 piece caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pad
-
Prevodník
32T, steel, X-Sync 2
