Rám

Foxy 29 6061 Alloy Stealth Evo, hydroformed tubing, Zero Suspension System, 150mm travel, Forward Geometry, one piece Monoblock upper link, Boost 12x148mm rear axle, tapered head tube, 73mm BSA bottom bracket, dedicated 1x drivetrain design, telescopic seatpost internal routing, MAX capacity sealed bearings, ISCG 05

Vidlica

Öhlins RXF 36 M.2 29, 160mm, TTX18 Twin Tube cartridge, tapered steerer tube, Boost 15x110mm axle, offset 44mm. Settings: high speed compression lever with climb mode, low-speed compression, rebound, air preload, ramp chamber

Hlavové zloženie

Onoff Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41x30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º

Prehadzovačka

Sram NX Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1

Brzdové páčky

Sram G2 R, SwingLink, tool-free reach adjust

Stredové zloženie

Sram DUB BSA, sealed bearings, 73mm

Radenie

Sram Trigger SX Eagle, 12s, X-Actuation 1:1

Riadidlá

Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9º backsweep, 5º upsweep, 31.8mm barbore

Kľuky

Sram SX Eagle, Boost, DUB axle, Direct Mount chain ring, S/M size: 170mm, L/XL size: 175mm

Predstavec

Onoff Sulfur FG 30mm 0º, 6061 forged alloy, 31.8mm barbore

Sedlovka

Onoff Pija dropper internal, diameter 31.6mm, S size: 337x100mm, M size 387x125mm, L size: 425x150mm, XL size: 465x170mm

Sedlo

SDG BEL-AIR 3.0, LPU foam, steel rails

Náboj Predný

DT 370, Boost 15x110mm, IS 6 bolts

Náboj zadný

DT 370, Boost 12x148mm, 18T Ratched LN system, IS 6 bolts,

Reťaz

Sram SX Eagle, 12s, Powerlock

Kazeta

Sram XG-1230, 11-50T, 12s

Drôty

DT Champion, straightpull

Rafíky

DT Swiss E1900 Spline 29, 30mm internal width, sleeved aluminum, tubeless ready, 28 spokes

Plášte

Maxxis Minion DHF 29x2.5 WT, tubeless ready, 3C MAXX TERRA compound, EXO+ protection, 120TPI, folding bead, Maxxis Aggressor 29x2.3, tubeless ready, dual compound, Exo protection, 60TPI, folding bead

Gripy

Onoff Diamond, 1lock-on, 135mm

Prevodník

32T, CNC-machined alloy, X-SYNC 2

Predná brzda

Sram G2 R, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads

Zadná brzda

Sram G2 R, 4-piston caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pads

Pätka k prehadzovačke

Mondraker M068

Tlmič

Öhlins TTX Air 205x62.5mm. Settings: high speed compression lever with climb mode, low-speed compression, rebound, air preload. Trunnion top mount, 22.2x10mm bottom bushings

Prevodník

32T, CNC-machined alloy, X-SYNC 2
