Vidlica

Fox 36 29 Float Performance GRIP, 160mm, 3 Position, tapered steerer tube, Boost 15x110mm axle, offset 44mm. Settings: sweep adjust compression, low-speed rebound, air preload

Radenie

Sram Trigger NX Eagle, 12s, X-Actuation 1:1

Kľuky

Truvativ Descendant 6K Eagle, Boost, DUB axle, Direct mount chain ring, S/M size: 170mm, L/XL size: 175mm

Riadidlá

Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9º backsweep, 5º upsweep, 31.8mm barbore

Pedále

SDG BEL-AIR 3.0, LPU foam, steel rails

Náboj predný

e*thirteen Boost 15x110mm, triple-sealed, fully machined aluminum, IS 6 bolts

Reťaz

Sram NX Eagle, 12s, Powerlock

Drôty

e*thirteen custom Hive triple-butted black steel, alloy nipples, nipple washers

Plášte

Maxxis Minion DHF 29x2.5 WT, tubeless ready, 3C MAXX TERRA compound, EXO+ protection, 120TPI, folding bead / Maxxis Minion DHR II 29x2.4 WT, tubeless ready, 3C MAXX TERRA compound, EXO+ protection, 120TPI, folding bead

Tlmič

Fox Float-X LV Performance, 205x65mm. Settings: compression 2 positions lever, low-speed rebound, air preload. Trunnion top mount, 30x8mm bottom bushings

Nastavenia tlmiča

Light compression, light rebound, air volume spacer 0.6

Pätka k prehadzovačke

Sram UDH

Rám

Foxy 29 Stealth Air full Carbon, Zero Suspension System, 150mm travel, Forward Geometry, aluminium CSC upper link with carbon bridge, Boost 12x148mm rear axle, tapered head tube, 73mm BSA bottom bracket, dedicated 1x drivetrain design, HHG internal cable routing, Enduro MAX sealed bearings, shock mudguard, ISCG 05, custom frame protectors. *Optional Geometry Kit.

Hlavové zloženie

Acros custom for 1-1/2

Prehadzovačka

Sram NX Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1

Brzdové páčky

Sram G2 R, tool-free reach adjust

Stredové zloženie

Sram DUB BSA, sealed bearings, 73mm

Predstavec

Onoff Sulfur FG 30mm 0º, 6061 forged alloy, 31.8mm barbore

Sedlovka

Onoff Pija dropper internal, diameter 31.6mm, S size: 405x95-125mm, M size 458x120-150mm, L size: 498x140-170mm, XL size: 498x140-170mm

Náboj zadný

e*thirteen Boost 12x148mm, triple-sealed, fully machined aluminum w/6-degree engagement, IS 6 bolts, Shimano freehub

Kazeta

Sram XG-1230, 11-50T, 12s

Ráfiky

e*thirteen LG1 Enduro, IW30 Hookless, 6069 Welded Aluminum, 30mm internal width, tubeless ready, 28 spokes

Gripy

Onoff Desert, 1lock-on, 135mm

Predná brzda

Sram G2 R, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads

Zadná brzda

Sram G2 R, 4-piston caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pads

Prevodník

32T, steel, X-Sync 2

Ostatné

*Optional Geometry kit: steering cups: +/- 1º
