Rám

Factor 24 6061 Alloy Stealth Evo, hydroformed tubing, Zero Suspension System, 100mm travel, one piece bolt-on upper link, QR 9mm rear axle, 73mm BSA bottom bracket, HHG internal cable routing, dedicated 1x drivetrain design. 26 wheelset compatible

Vidlica

X-Fusion Velvet RL2 26, 100mm, Motion control, air spring, tapered steerer tube, 9x100mm axle, 32mm aluminum stanchions, 41mm offset. Settings: lockout, rebound, air preload

Hlavové zloženie

Onoff Saturn tapered for 1-1/8 to 1-1/2 head tube, ACB sealed bearings, top 41x30.2x7x45x45, bottom 51.9x40x8x45x45

Prehadzovačka

Sram SX Eagle, Type 3 roller bearing clutch, cage lock, long cage, 1x12s, X-actuation 1:1

Radenie

Sram Trigger SX Eagle, 12s, X-Actuation 1:1

Brzdové páčky

Shimano M4100, alloy lever, tooled reach adjust

Kľuky

Sram SX Eagle, DUB axle, Direct mount chain ring, 155mm

Stredové zloženie

Sram DUB BSA, sealed bearings, 73mm

Riadidlá

SDG Slater, double butted 6061 alloy, rise: 20mm, width: 650mm, 5 backsweep, 8 upsweep, 31.8mm barbore with 4x19mm shims SDG Slater JR D19mm, 115mm

Predstavec

Onoff Sulfur FG 30mm 0, 6061 forged alloy, 31.8mm barbore

Sedlovka

Onoff Sulfur 0-R, 6061 T6 Alloy, 3D forged, diameter 31.6mm, length 400mm

Sedlo

SDG Fly JR

Náboj Predný

Formula DC20LW, 9x100mm, cup cone ball bearings, IS 6 bolts

Náboj zadný

Formula DC22LW 9x135mm, cup cone ball bearings, IS 6 bolts

Reťaz

Sram SX Eagle, 12s, Powerlock

Kazeta

Sram PG-1230, 11-50T, 12s

Drôty

CN round stainless steel

Ráfiky

MDK-XP1 24 TLR, 23mm internal width, tubeless ready, 32 spokes

Plášte

Kenda Booster 24x2.4 single compound 30TPI, wire bead

Tlmič

X-Fusion 02PRO R, 210x47.5mm. Settings: low-speed rebound, air preload. 45x8mm top and bottom bushings

Brzdy

Shimano M410, RT56 160mm IS 6 bolts rotor, resin pads

Plášť zadný

Kenda Booster 24x2.4 single compound 30TPI, wire bead

Nastavenia tlmiča

A-Tune light compression

Prevodník

30T, steel, X-Sync

Pätka k prehadzovačke

Mondraker M073

Hmotnosť

12,3 Kg
