Rám

Chrono 29 6061 Xtralite Alloy butted, XC Forward Geometry, 73mm BSA bottom bracket, tapered head tube, HHG Internal Cable Routing, Boost 12x148mm rear axle

Vidlica

RockShox Judy Silver TK 29, 100mm, TurnKey, Solo Air, tapered steerer tube, 9x100mm axle, 30mm steel stanchions, 46mm offset. Settings: Poplock 2 pos remote compression (open/lock), rebound, air preload

Hlavové zloženie

Onoff Saturn tapered for 1-1/8 to 1-1/2 head tube, ACB sealed bearings, top 41x30.2x7x45x45, bottom 51.9x40x8x45x45

Prehadzovačka

Sram SX Eagle, Type 3 roller bearing clutch, cage lock, long cage, 1x12s, X-actuation 1:1

Brzdové páčky

Sram Level, tooled reach adjust, lever pivot bushings

Stredové zloženie

Sram DUB BSA, sealed bearings, 73mm

Riadidlá

Onoff Sulfur 0.2, double butted 6061 alloy, rise: 4.8mm, width: 740mm, 9 backsweep, 0 upsweep, 31.8mm barbore Onoff Twin, 1lock-on, 135mm

Predstavec

Onoff Sulfur, 6061 T6 Alloy, 31.8mm barbore, rise: +/-7, length: sizes S/M: 60mm, size L: 80mm, size XL: 90mm

Sedlovka

Onoff Sulfur 0-R, 6061 T6 Alloy, 3D forged, diameter 27.2mm, length 400mm

Sedlo

Mondraker XC Series, steel rail

Náboj Predný

Formula DC20LW, 9x100mm, cup cone ball bearings, IS 6 bolts

Náboj zadný

Formula MST148S-4SB, Boost 12x148mm, sealed bearings, IS 6 bolts, MS freehub

Reťaz

Sram SX Eagle, 12s, Powerlock

Kazeta

Sram PG-1210, 11-50T, 12s

Drôty

CN round stainless steel

Plášte

Kenda Slant Six 29x2.20, wire bead

Prevodník

34T, steel, X-Sync 2

Pätka k prehadzovačke

Mondraker M074

Hmotnosť

12,7 Kg
