Rám

Level 6061 Alloy Stealth Evo, e-Bike Optimized Zero Suspension System, 170mm travel, Forward Geometry, internal removable battery with integrated alloy cover, Boost 12x148mm rear axle, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 17mm axles, integrated dropout speed sensor, exclusive plastic motor covers

Vidlica

Fox 38 29 Float FIT GRIP EVOL Performance, 180mm, e-bike tuned, tapered steerer tube, Boost 15x110mm axle, 44mm offset. Settings: 3 positions with micro adjust compression, low-speed rebound, air preload

Prehadzovačka

Sram GX Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1

Hlavové zloženie

Onoff Saturn tapered for 1-1/8 to 1-1/2 head tube, ACB sealed bearings, top 41x30.2x7x45x4, bottom 51.9x40x8x45x45

Brzdové páčky

Sram Code R, tool-free reach adjust

Kľuky

Race Face Aeffect, 165mm

Riadidlá

Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 780mm, 9º backsweep, 5 upsweep, 31.8mm barbore,Onoff Desert, 1lock-on, 135mm, sizes: S/M L/XL

Predstavec

Onoff Sulfur FG 30mm 0, 6061 forged alloy, 31.8mm barbore

Sedlo

SDG BEL-AIR 3.0, EVA foam, steel rails

Sedlovka

Onoff Pija dropper internal, diameter 31.6mm, S size: 387x125mm, M size: 425x150mm, L/XL size: 465x170mm

Náboj predný

DT 370, Boost 15x110mm, IS 6 bolts

Náboj zadný

DT 370, Boost 12x148mm, 3 Pawl system, IS 6 bolts

Kazeta

Sram PG-1210, 11-50T, 12s

Reťaz

Sram SX Eagle, 12s, Powerlock

Drôty

DT Hybrid SP, straightpull

Ráfiky

DT Swiss H1900 Spline 29, 30mm internal width, sleeved aluminum, tubeless ready, 28 spokes

Tlmič

Fox DHX2 Performance Elite, 225x75mm. Settings: low-speed compression, low-speed rebound, spring preload. Trunnion top mount, 25x10mm bottom bushings

Predná brzda

Sram Code R, oversized 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed metal sintered pads

Zadná brzda

Sram Code R, oversized 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed metal sintered pads

Plášť zadný

Maxxis Assegai 29x2.5WT, tubeless ready, 3C MAXX GRIP compound, DH casing, 60x2TPI, folding bead

Prevodník

Sram X-Sync 2 Eagle 34T, steel, narrow-wide, 104 BCD

Pätka k prehadzovačke

Mondraker M068

Motor + Batéria

Bosch Performance Line CX Cruise (25Km/h) GEN4, computer Bosch Kiox, Bosch Powertube 625Wh

Hmotnosť

26,1 kg (pri veľkosti L)
