Rám
Crafty 6061 Alloy Stealth Evo, e-Bike Optimized Zero Suspension System, 150mm travel, Forward Geometry, internal removable battery with integrated alloy cover, Boost 12x148mm rear axle, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 17mm axles, integrated dropout speed sensor, exclusive plastic motor covers.
-
Vidlica
Fox 38 29 Float FIT GRIP EVOL Performance, 160mm, e-bike tuned, tapered steerer tube, Boost 15x110mm axle, 44mm offset. Settings: 3 positions with micro adjust compression, low-speed rebound, air preload
-
Prehadzovačka
Sram GX Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1
-
Brzdové páčky
Sram G2 R, tool-free reach adjust
-
Riadidlá
Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 780mm, 9 backsweep, 5 upsweep, 31.8mm barbore Onoff Desert, 1lock-on, 135mm, sizes: S/M L/XL
-
Sedlo
SDG BEL-AIR 3.0, EVA foam, steel rails
-
Sedlovka
Onoff Pija dropper internal, diameter 31.6mm, S size: 387x125mm, M size: 425x150mm, L/XL size: 465x170mm
-
Náboj predný
DT 370, Boost 15x110mm, IS 6 bolts
-
Náboj zadný
DT 370, Boost 12x148mm, 3 Pawl system, IS 6 bolts
-
Kazeta
Sram PG-1210, 11-50T, 12s
-
Reťaz
Sram SX Eagle, 12s, Powerlock
-
Drôty
DT Hybrid SP, straightpull
-
Ráfiky
DT Swiss H1900 Spline 29, 30mm internal width, sleeved aluminum, tubeless ready, 28 spokes
-
Tlmič
Fox Float DPX2 LV EVOL Performance, 205x65mm. Settings: compression 3 positions lever, low-speed rebound, air preload. Trunnion top mount, 25x10mm bottom bushings
-
Predná brzda
Sram G2 R, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads
-
Zadná brzda
Sram G2 R, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads
-
Plášť zadný
Maxxis Minion DHR II 29x2.6, tubeless ready, 3C MAXX TERRA, EXO+ Protection, 120TPI, folding bead
-
Prevodník
Sram X-Sync 2 Eagle 34T, steel, narrow-wide, 104 BCD
-
Pätka k prehadzovačke
Mondraker M068
-
Motor + Batéria
Bosch Performance Line CX Cruise (25Km/h) GEN4, computer Bosch Kiox, Bosch Powertube 625Wh
-
Hmotnosť
23,7 kg (pri veľkosti L)
