Rám
Crafty Stealth Air full Carbon
-
Prehadzovačka
Sram GX Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1
-
Brzdové páčky
Sram G2 RSC, SwingLink and lever pivot bearings, tools-free reach and contact point adjust
-
Riadidlá
Onoff Krypton 1.0 double butted 6061 alloy
-
Sedlo
Fizik Antares R7
-
Náboj zadný
DT 370, Boost 12x148mm, 3 Pawl system, IS 6 bolts
-
Kazeta
Sram XG-1230, 11-50T, 12s
-
Ráfiky
DT Swiss H1900 Spline 29, 30mm internal width, sleeved aluminum, tubeless ready, 28 spokes
-
Predná brzda
Sram G2 RSC, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads
-
Plášť zadný
Maxxis Minion DHR II 29x2.6, tubeless ready, 3C MAXX TERRA, EXO+ Protection, 120TPI, folding bead
-
Prevodník
Sram X-Sync 2 Eagle 34T, alloy, narrow-wide, 104 BCD
-
Motor + batérie
Bosch Performance Line CX Cruise (25Km/h) GEN4, computer Bosch Kiox, Bosch Powertube 625Wh
-
Vidlica
Fox 36 29 Float FIT GRIP EVOL Performance
-
Hlavové zloženie
Acros custom for 1-1/2 head tube, angular contact bearings 40x52x7
-
Radenie
Sram Trigger NX Eagle, 12s, X-Actuation 1:1, single click
-
Kľuky
Race Face Aeffect, 165mm
-
Predstavec
Onoff Krypton FG 30mm, 6061 forged alloy, 31.8mm barbore
-
Sedlovka
Onoff Pija dropper internal, diameter 31.6mm, S size: 387x125mm, M size: 425x150mm, L/XL size: 465x170mm
-
Náboj predný
DT 370, Boost 15x110mm, IS 6 bolts
-
Reťaz
Sram NX Eagle, 12s, Powerlock
-
Drôty
DT Hybrid SP, straightpull
-
Plášte
Maxxis Minion DHF 29x2.6, tubeless ready, 3C MAXX TERRA, EXO+ Protection, 120TPI, folding bead
-
Tlmič
Fox Float DPS Performance, 205x65mm. Settings: Compression 3 positions lever, low-speed rebound, air preload. Trunnion top mount, 25x10mm bottom bushings
-
Zadná brzda
Sram G2 RSC, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads
-
Nastavenia tlmiča
Medium compression, Medium rebound, 0.4 volume spacer
-
Päťka k prehadzovačke
Mondraker M068
-
Hmotnosť
23,7 kg (pri veľkosti L)
