Vidlica

Fox 36 29 Float FIT GRIP EVOL Rhythm, 160mm, e-bike tuned, tapered steerer tube, Boost 15x110mm axle, 44mm offset. Settings: sweep adjust compression, Low-speed rebound, air preload

Radenie

Sram Trigger SX Eagle, 12s, X-Actuation 1:1, single click

Kľuky

Race Face Aeffect ebike, 165mm

Predstavec

Onoff Sulfur FG 30mm 0º, 6061 forged alloy, 31.8mm barbore

Sedlo

MDK ebike black

Náboj zadný

Mavic, Boost 12x148mm, ID360 Ratched system, IS 6 bolts

Kazeta

Sram PG-1210, 11-50T, 12s

Ráfiky

Mavic E-Deemax 29, 30mm internal width, welded, PFP, tubeless ready, 28 spokes

Tlmič

Fox Float DPS Performance, 205x65mm. Settings: Compression 3 positions lever, low-speed rebound, air preload. Trunnion top mount, 25x10mm bottom bushings

Nastavenia tlmiča

Medium compression, medium rebound, air volume spacer 0.4

Pätka k prehadzovačke

Mondraker M068

Rám

Chaser 6061 Alloy Stealth Evo, e-Bike Optimized Zero Suspension System, 150mm travel, Forward Geometry, internal non-removable battery, Boost 12x148mm rear axle, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 17mm axles, integrated dropout speed sensor, exclusive plastic motor covers, shock mudguard

Hlavové zloženie

Onoff Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41x30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º

Prehadzovačka

Sram GX Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1

Brzdové páčky

Sram DB8, tool-free reach adjust

Riadidlá

Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9º backsweep, 5º upsweep, 31.8mm barbore

Sedlovka

Onoff Pija dropper internal, diameter 31.6mm, S size: 405x95-125mm, M size 458x120-150mm, L size: 498x140-170mm, XL size: 498x140-170mm

Náboj predný

Mavic, Boost 15x110mm, IS 6 bolts

Reťaz

Sram SX Eagle, 12s, Powerlock

Drôty

Mavic J-bend double butted, contactless lacing

Plášte

Maxxis Rekon 29x2.6, tubeless ready, dual compound, EXO protection, 60TPI, folding bead

Gripy

Onoff Twin, 1lock-on, 135mm

Predná brzda

Sram DB8, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads

Zadná brzda

Sram DB8, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads

Prevodník

Sram X-Sync 2 Eagle 34T, steel, narrow-wide, 104 BCD

Motor + Batérie

Bosch Performance Line CX Cruise (25Km/h) Smart System , Bosch Powertube 750Wh, Bosch Intuvia 100 / Bosch Mini Remote / Bosch System Controller
