Rám

Chaser 6061 Alloy Stealth Evo, e-Bike Optimized Zero Suspension System, 150mm travel, Forward Geometry, internal removable battery, Boost 12x148mm rear axle, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 17mm axles, integrated dropout speed sensor, exclusive plastic motor covers, shock mudguard

Vidlica

RockShox 35 Silver TK 29, 160mm, TurnKey, Solo Air, tapered steerer tube, Boost 15x110mm axle, 35mm steel stanchions, 44mm offset. Settings: compression adjustment at low-speed to lock, rebound, air preload

Prehadzovačka

Sram SX Eagle, Type 3 roller bearing clutch, cage lock, long cage, 1x12s, X-actuation 1:1

Hlavové zloženie

Onoff Saturn tapered for 1-1/8 to 1-1/2 head tube, ACB sealed bearings, top 41x30.2x7x45x45, bottom 51.9x40x8x45x45

Brzdové páčky

Sram G2 R, tool-free reach adjust

Kľuky

Race Face Aeffect ebike, 165mm

Riadidlá

Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 780mm, 9 backsweep, 5 upsweep, 31.8mm barbore Onoff Twin, 1lock-on, 135mm

Predstavec

Onoff Sulfur FG 30mm 0, 6061 forged alloy, 31.8mm barbore

Sedlo

Mondraker e-MTB custom design

Sedlovka

Onoff Pija dropper internal, diameter 31.6mm, S size: 387x125mm, M size: 425x150mm, L/XL size: 465x170mm

Náboj predný

Formula DC711, Boost 15x110mm, sealed bearings, IS 6 bolts

Náboj zadný

Formula EHL148 Boost 12x148mm, sealed bearings, IS 6 bolts

Kazeta

Sram PG-1210, 11-50T, 12s

Reťaz

Sram SX Eagle, 12s, Powerlock

Drôty

CN round stainless steel

Ráfiky

MDK-HP1 29, 30mm internal width, tubeless ready, 32 spokes

Plášte

Maxxis Rekon 29x2.6, tubeless ready, dual compound, EXO protection, 60TPI, folding bead

Tlmič

RockShox Deluxe Select R Debonair, 205x65mm. Settings: Low-speed rebound, air preload. Trunnion top mount, 25x10mm bottom bushings

Predná brzda

Sram G2 R, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads

Zadná brzda

Sram G2 R, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads

Plášť zadný

Maxxis Rekon 29x2.6, tubeless ready, dual compound, EXO protection, 60TPI, folding bead

Nastavenia tlmiča

Light compression, Light rebound, 1 Token

Prevodník

Sram X-Sync 2 Eagle 34T, steel, narrow-wide, 104 BCD

Pätka k prehadzovačke

Mondraker M068

Motor + Batéria

Bosch Performance Line CX Cruise (25Km/h) GEN4, computer Bosch Purion, Bosch Powertube 625Wh

Hmotnosť

24,8 kg (pri veľkosti L)
