Rám
Play 20 6061 Alloy Stealth evo, hydroformed tubing, integrated internal non-removable battery, Tapered head tube, HHG internal cable routing, BSA bottom bracket, QR 9mm rear axle, 1x drivetrain compatible
-
Vidlica
MDK 20 Kid, Rigid alloy Stealth stanchions, Post Mount disc brake mount
-
Prehadzovačka
Microshift M26S, 9s, short cage
-
Hlavové zloženie
Onoff Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41x30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º
-
Brzdové páčky
Shimano M6100, servo wave, alloy lever, tooled reach adjust
-
Kľuky
Prowheel, Direct mount chain ring, 114mm
-
Predstavec
Onoff Sulfur FG 30mm 0º, 6061 forged alloy, 31.8mm barbore
-
Riadidlá
MDK XC 1.0, 6061 alloy, rise: 25mm, width: 580mm, 9º backsweep, 5º upsweep, 31.8mm barbore
-
Sedlo
SDG Fly JR
-
Sedlovka
MDK XC 0-R, 6061 T6 Alloy, diameter 31.6mm, length 250mm
-
Náboj predný
Formula DC20LW, 9x100mm, cup & cone ball bearings, IS 6 bolts
-
Náboj zadný
Mahle-Ebikemotion X-35
-
Kazeta
Microshift Mezzo 11-34T, 9s
-
Reťaz
Sram PC951 9s, Powerlock
-
Ráfiky
MDK-XP1 20 TLR, 25mm internal width, tubeless ready, 32 spokes
-
Predná brzda
Shimano M6100, RT56 160mm IS 6 bolts rotor, resin pads
-
Zadná brzda
Shimano M6100, RT56 160mm IS 6 bolts rotor, resin pads
-
Gripy
Kids
-
Plášť
Kenda Booster 20x2.4 single compound 30TPI, wire bead, Kenda Booster 20x2.4 single compound 30TPI, wire bead
-
Prevodník
28T, steel
-
Pätka k prehadzovačke
Mondraker M073
-
Motor + Batéria
Mahle-Ebikemotion X-35, Mahle-Ebikemotion Internal 250Wh, Mahle-Ebikemotion,
-
Hmotnosť
12,9 Kg
